• Specifications:

    Current Rating: 1A
    Insulation Resistance: 1000 MΩ min.
    Contact Resistance: 20 mΩ max.
    Dielectric Withstanding : AC 500V
    Operating Temperature : -40℃~+105℃
    Max. Processing Temp. : 245±5℃ for 3~5 seconds(NY6T/NY9T)
    Contact Material : Brass
    Insulator Material : Nylon-6T(H.F.)/Nylon-9T,UL94V-0(Black)
    Finish : 0.6u" Gold plated on contact area
    Packing : Tray

    PDF
